25A 3P MCB
US Build
Currency
0

25A 3P MCB

Write a review
Non-returnable
Tags:
25A TP MCB is designed for three-phase electrical circuits and provides effective protection against overload and short-circuit conditions. It is widely used in industrial and commercial electrical panels.

₹522.06

Choose Quantity

Add to Cart. . .
Product Details
Specifications

Main
Device applicationDistribution
Range of productActi9
RangeActi9
Product nameXC60
Product or component typeMiniature circuit-breaker
Device short namexC60
Poles description3P
Number of protected poles3
[In] rated current25 A
Network typeDC
AC
Trip unit technologyThermal-magnetic
Curve codeD
Utilisation categoryCategory A conforming to IS/IEC 60947-2
Suitability for isolationYes conforming to IS/IEC 60947-2
Complementary
Network frequency50/60 Hz
[Ue] rated operational voltage220...240 V AC 50/60 Hz
380...415 V AC 50/60 Hz
100...125 V DC
Magnetic tripping limit12 x In +/- 20 %
Breaking capacity10 kA Inc at 380...415 V AC 50/60 Hz conforming to IS/IEC 60947-2
15 kA Icu at 100...125 V DC conforming to IS/IEC 60947-2
[Ics] rated service breaking capacity7.5 kA conforming to IS/IEC 60947-2 - 380...415 V AC 50/60 Hz
15 kA conforming to IS/IEC 60947-2 - 100...125 V DC
Limitation class3 conforming to IS/IEC 60947-2
[Ui] rated insulation voltage500 V AC 50/60 Hz conforming to IS/IEC 60947-2
[Uimp] rated impulse withstand voltage4 kV conforming to IS/IEC 60947-2
Contact position indicatorYes
Control typeToggle
Local signallingON/OFF indication
Mounting modeClip-on
Mounting support35 mm DIN rail
Comb busbar and distribution block compatibilityTop: YES
9 mm pitches6
Height85 mm
Width54 mm
Depth77.5 mm
Net weight0.31 kg
ColourWhite
Mechanical durability20000 cycles
Electrical durability10000 cycles
Connections - terminalsTunnel type terminals (bottom) 16 mm² flexible
Tunnel type terminals (bottom) 25 mm² rigid
Biconnect (bottom)
Wire stripping length13 mm for top or bottom connection
Tightening torque2 N.m
Earth-leakage protectionSeparate block
Product compatibilityC60 accessories
C60 auxiliary
Overvoltage categoryIV
Environment
StandardsIS/IEC 60947-2
IP degree of protectionIP20
Pollution degree3
Tropicalisation2 conforming to IEC 60068-1
Relative humidity95 % at 55 °C
Ambient air temperature for operation-30…70 °C
Ambient air temperature for storage-40…85 °C
Packing Units
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height8.1 cm
Package 1 Width5.35 cm
Package 1 Length7.4 cm
Package 1 Weight350 g
Unit Type of Package 2BB1
Number of Units in Package 24
Package 2 Height8 cm
Package 2 Width9 cm
Package 2 Length23.8 cm
Package 2 Weight1.462 kg
Unit Type of Package 3CAR
Number of Units in Package 348
Package 3 Height27 cm
Package 3 Width30 cm
Package 3 Length35 cm
Package 3 Weight18.144 kg
Contractual warranty
Warranty (in months)18
Electrical Rating
  • Current Rating
    25 A
  • Voltage Rating
    230V AC
  • Frequency
    50 / 60 Hz
  • Trip Curve
    D Curve
  • Number of Poles
    3P
Product Details
  • Product Type
    MCB
  • Color
    White
  • Breaking Capacity
    10kA
