The Acti9 iC60N is a 4P low voltage miniature circuit breaker (MCB) with 16A rated current and a C tripping curve. Designed for both industrial (EN/IEC 60947-2) and residential (EN/IEC 60898-1) standards, it offers a breaking capacity of up to 20kA at 240VAC. This MCB provides reliable protection against short circuits and overloads, featuring the unique VisiTrip indicator to reduce intervention time by clearly signaling the faulty circuit.

₹1,534.56 ₹3,197.00

Choose Quantity

Add to Cart. . .
Product Details
Specifications
Main
Device applicationDistribution
RangeActi9
Product nameActi9 iC60
Product or component typeMiniature circuit-breaker
Device short nameIC60N
Poles description4P
Number of protected poles4
[In] rated current16 A
Network typeDC
AC
Trip unit technologyThermal-magnetic
Curve codeC
Breaking capacity36 kA Icu at 12...133 V AC 50/60 Hz conforming to EN/IEC 60947-2
20 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-2
10 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-2
6 kA Icu at 440 V AC 50/60 Hz conforming to EN/IEC 60947-2
10 kA Icu at <= 250 V DC conforming to EN/IEC 60947-2
6000 A Icn at 400 V AC 50/60 Hz conforming to EN/IEC 60898-1
Utilisation categoryCategory A conforming to EN/IEC 60947-2
Suitability for isolationYes conforming to EN/IEC 60898-1
Yes conforming to EN/IEC 60947-2
StandardsEN/IEC 60947-2
EN/IEC 60898-1
Complementary
Network frequency50/60 Hz
Magnetic tripping limit8 x In +/- 20 %
[Ics] rated service breaking capacity27 kA 75 % conforming to EN/IEC 60947-2 - 12...133 V AC 50/60 Hz
15 kA 75 % conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz
7.5 kA 75 % conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz
4.5 kA 75 % conforming to EN/IEC 60947-2 - 440 V AC 50/60 Hz
10 kA 100 % conforming to EN/IEC 60947-2 - <= 250 V DC
Limitation class3 conforming to EN/IEC 60898-1
[Ui] rated insulation voltage500 V AC 50/60 Hz conforming to EN/IEC 60947-2
[Uimp] rated impulse withstand voltage6 kV conforming to EN/IEC 60947-2
Contact position indicatorYes
Control typeToggle
Local signallingTrip indicator
Mounting modeFixed
Mounting supportDIN rail
Comb busbar and distribution block compatibilityTop or bottom: YES
9 mm pitches8
Height85 mm
Width72 mm
Depth78.5 mm
Net weight0.5 kg
ColourWhite
Mechanical durability20000 cycles
Electrical durability10000 cycles
Connections - terminalsSingle terminal (top or bottom) 1…25 mm² rigid
Single terminal (top or bottom) 1…16 mm² flexible
Wire stripping length14 mm for top or bottom connection
Tightening torque2 N.m top or bottom
Earth-leakage protectionSeparate block
Environment
IP degree of protectionIP20 conforming to IEC 60529
Pollution degree3 conforming to EN/IEC 60947-2
Overvoltage categoryIV
Tropicalisation2 conforming to IEC 60068-1
Relative humidity95 % at 55 °C
Operating altitude0...2000 m
Ambient air temperature for operation-35…70 °C
Ambient air temperature for storage-40…85 °C
Packing Units
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height7.100 cm
Package 1 Width7.300 cm
Package 1 Length9.300 cm
Package 1 Weight430.000 g
Unit Type of Package 2BB1
Number of Units in Package 23
Package 2 Height8.200 cm
Package 2 Width10.000 cm
Package 2 Length22.600 cm
Package 2 Weight1.358 kg
Unit Type of Package 3S03
Number of Units in Package 333
Package 3 Height30.000 cm
Package 3 Width30.000 cm
Package 3 Length40.000 cm
Package 3 Weight15.620 kg
Contractual warranty
Warranty (in months)18
Electrical Rating
  • Current Rating
    16 A
  • Voltage Rating
    440V AC
  • Frequency
    50 / 60 Hz
  • Trip Curve
    C Curve
  • Number of Poles
    4P
Product Details
  • Product Type
    MCB
  • Color
    White
  • Breaking Capacity
    36kA
Standards & Safety
  • Certification
    IS / IEC
  • Safety Feature
    Shock Proof
