This Acti9 C60H-DC is a low voltage direct current miniature circuit breaker (MCB). It has 2P, rated current 32A and C tripping curve. The rated short circuit breaking capacity goes up to 20kA at 220VDC conforming to GB 14048.2 standard and 20kA at 220VDC conforming to GB 14048.2 standard. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker combines functions of circuit protection against short circuit and overload current, control and isolation. It offers VisiTrip for safety during maintenance

₹312.96 ₹625.92

Choose Quantity

Add to Cart. . .
Product Details
Specifications
Main
RangeActi9
Product nameActi9 C60H-DC
Product or component typeMiniature circuit-breaker
Device short nameC60H-DC
Device applicationDistribution
Poles description2P
Number of protected poles2
[In] rated current32 A at 25 °C
Network typeDC
Trip unit technologyThermal-magnetic
Curve codeC
Breaking capacity10 kA Icu at 440 V DC conforming to EN 60947-2
10 kA Icu at 440 V DC conforming to IEC 60947-2
6 kA Icu at 500 V DC conforming to EN 60947-2
6 kA Icu at 500 V DC conforming to IEC 60947-2
20 kA Icu at 220 V DC conforming to GB 14048.2
20 kA Icu at 220 V DC conforming to IEC 60947-2
20 kA Icu at 250 V DC conforming to GB 14048.2
20 kA Icu at 250 V DC conforming to IEC 60947-2
Utilisation categoryCategory A conforming to EN 60947-2
Category A conforming to IEC 60947-2
Suitability for isolationYes conforming to IEC 60947-2
Yes conforming to EN 60947-2
StandardsEN 60947-2
IEC 60947-2
Complementary
Network frequency50/60 Hz
[Ue] rated operational voltage500 V DC
[Ics] rated service breaking capacity15 kA 75 % conforming to EN 60947-2 - 220 V DC
15 kA 75 % conforming to IEC 60947-2 - 220 V DC
15 kA 75 % conforming to EN 60947-2 - 250 V DC
15 kA 75 % conforming to IEC 60947-2 - 250 V DC
4.5 kA 75 % conforming to EN 60947-2 - 500 V DC
4.5 kA 75 % conforming to IEC 60947-2 - 500 V DC
7.5 kA 75 % conforming to EN 60947-2 - 440 V DC
7.5 kA 75 % conforming to IEC 60947-2 - 440 V DC
[Ui] rated insulation voltage500 V DC conforming to IEC 60947-2
500 V DC conforming to EN 60947-2
[Uimp] rated impulse withstand voltage6 kV conforming to EN 60947-2
6 kV conforming to IEC 60947-2
Contact position indicatorYes
Control typeToggle
Local signallingON/OFF indication
Mounting modeFixed
Mounting support35 mm symmetrical DIN rail
Comb busbar and distribution block compatibilityTop or bottom: standard
9 mm pitches4
Net weight0.256 kg
ColourWhite
Mechanical durability20000 cycles
Electrical durability3000 cycles L/R = 2 ms
Provision for padlockingPadlockable
Locking options descriptionIn position O
Tightening torquePower circuit: 2.5 N.m top or bottom
Earth-leakage protectionWithout
Environment
Pollution degree3 conforming to EN 60947-2
3 conforming to IEC 60947-2
Overvoltage categoryIV
Tropicalisation2 conforming to IEC 60068-2
Operating altitude2000 m
Ambient air temperature for operation-25…70 °C
Ambient air temperature for storage-40…85 °C
Packing Units
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height7.300 cm
Package 1 Width3.200 cm
Package 1 Length8.500 cm
Package 1 Weight243.000 g
Unit Type of Package 2BB1
Number of Units in Package 26
Package 2 Height8.000 cm
Package 2 Width9.000 cm
Package 2 Length22.500 cm
Package 2 Weight1.507 kg
Unit Type of Package 3S03
Number of Units in Package 372
Package 3 Height30.000 cm
Package 3 Width30.000 cm
Package 3 Length40.000 cm
Package 3 Weight18.703 kg
Contractual warranty
Warranty (in months)18
Electrical Rating
  • Current Rating
    32 A
  • Voltage Rating
    440V AC
  • Frequency
    50 / 60 Hz
  • Trip Curve
    C Curve
  • Number of Poles
    2P
Product Details
  • Product Type
    MCB
  • Color
    White
  • Breaking Capacity
    20kA
Material & Build
  • Material
    Polycarbonate
  • Fire Resistance
    Yes
  • Durability
    High
Application
  • Usage Area
    Commercial
  • Application
    Lighting
